Freatures: •Use for repair damaging backlight processing. (Processing for one time 0.05~0.5mm) •Finishing processing with no vestige after cutting on the products end face of right angle. (Cutting tools are optional) •This machine uses pneumatic pressure type synchronization to clamp the material, therefore the machine operation is easy, the efficiency is very high. •This machine may depend on the client the special demand, but other design custom make. Extremely welcome the client incoming sample, custom make.
	Type YC-6100 YC-6120 Max. cutting thickness 60mm 60mm Max. cutting length 1000mm 1200mm Processing for one time 0.05~0.5mm (With percentage chart) 0.05~0.5mm (With percentage chart) Spindle motor 5HP x 1 5HP x 1 Spindle speed Max. 6000rpm (Variable speed adjustable) Max. 6000rpm (Variable speed adjustable) Working table transfer motor 0.5 HP 0.5 HP Working table area 410 x 1050mm 410 x 1250mm Working speed adjustable Variable speed adjustable Variable speed adjustable Working angle End face of right angle End face of right angle Cutting tools Crude working toolx1, Fine working toolx1 Crude working toolx1, Fine working toolx1 Dust chute outlet diameter 100mm 100mm Machine size 3200 x 1000 x 1600mm 3550 x 1000 x 1600mm Machine weight 2800kgs 3300kgs *All specification, dimensions and design characteristics are subject to change without prior notice.
